Real-time process control for the cement industry
시멘트 산업을 위한 실시간 공정 제어
CNA Pentos-Cement는 PFTNA(Pulsed Fast and Thermal Neutron Activation) 기술에 기반한 세계 최고의 5세대 고급 온라인 원소 분석기입니다. 제품의 장점으로는 샘플 추출 타워의 교체, 테스트 및 전처리 작업 감소를 통한 연구실 비용 절감, 맞춤형 원료 공급을 통한 분쇄 효율 증가, 에너지 비용 절감, 원료 혼합물의 실시간 첨가제 제어를 통한 첨가제 사용량 절약 및 원료 분쇄 결과물의 품질 향상 등이 있습니다.
- On-off electric neutron source
- Automated radiation protection system (ARPS)
- Modular design for minimum downtime during installation
- Built-in direct link diagnostics program, ensuring optimum operation and uptime
- Constant neutron flux eliminates expensive and inconvenient periodic on-site calibration
The benefits of PFTNA
Using pulsed fast thermal neutron activation (PFTNA) analysis, the CNA Pentos cross-belt analyzer is able to quickly determine the chemistry of raw materials which enables high-frequency process control. By ’illuminating’ the material with neutrons, the CNA analyzes the bulk of the material on a belt from top to bottom and side to side delivering highly representative data. Pulsed excitation produces high-quality time-resolved gamma ray spectra from the sample. This provides high precision and accuracy with a drastically improved signal-to-noise ratio.
Installation of a CNA Pentos at the quarry makes it possible to effectively utilize lower grade materials by providing rapid analyses of the material going to the stockpile. This can significantly increase the lifetime of the quarry.
A CNA Pentos-Cement ahead of the stockpile ensures that pile quality targets are met, chemical variation is reduced, and minimal correction is required upon reclaim.
Raw mix control
Using the CNA Pentos, the raw mix chemistry is measured at 1 minute intervals. This enables immediate correction of mix proportioning ratios with no mill transport delay. The end result is a raw mix that is both stable and on target, enabling stable kiln operation and the resulting reduction in fuel consumption and extension of refractory life.
Cost saving opportunities
- Improving kiln operation
- Reducing laboratory cost and preparation labor
- Improving grinding efficiency while reducing energy cost to grind
- Improving lifetime of kiln refractory
- Reducing use of additives
- Extending quarry life
|Methods||Pulsed fast & thermal neutron activation analysis||Safety loop||ARP System (automatic radiation protections system)||Features||Non-material specific|
|Generator||Electrical neutron generator (on/off)||Radiation levels||Compliant with European council directive 96/29/ EURATOM||Unaffected by varying belt loading|
|Quantified elements||Si, Al, Fe, Ca, Mg, S, Na, K, Ti, Mn, H, Cl||No radiation when the CNA is not in operation||Stable analytical performance (SAP) system|
|Cement parameters||LSF, C3S, C2S, C3A, iron modulus, silica modulus|
