The fact that this fusion instrument allows the easy loading of crucibles, molds and beakers, that it has over ten preset fusion programs and that is ready to use right of the box without any training makes it really easy to use. LeNeo fusion instrument is also known to enhance security for the operator since its safety door automatically locks to protect him against heat. The fully automated pouring avoids the manipulation of hot vessels.
Claisse LeNeo fusion instrument helps obtaining superior analytical performances as well as accurate and precise results. Its programmable fusion parameters ensure high fusion success rate.

Features and benefits

High analytical performance

• Heating chamber temperature up to 1200°C
• Repeatable (absolute control of the fusion temperature)
• High accuracy
• Controlled or maximum heating rate to optimize oxidation and fusion success rate

Programme fusion parameters

• Temperature
• Duration
• Heating rate
• Crucible rocking speed
• Cooling air flow
• Magnetic stirring speed for solutions
• 4 pouring modes

Ready to use right out of the box

• Fully automatic one-touch operation
• Library of predefined fusion methods
• No training required for operation
• Easy loading of crucible, mold and beaker

Ultimate safety

• Fully automated pouring
• No manipulation of hot vessels (cold-to-cold operation)
• Safety door that automatically locks during the entire fusion process

Quick return on investment and low cost of ownership

• 3 preparation modes in 1 instrument
• Easy routine maintenance
• Optimum up-time guaranteed
• Quick and easy replacement of internal refractory plates

Easy installation

• Small and compact: fits in limited space
• Simple electrical connection
• No O2, compressed air or water cooling system needed

Key applications

The Claisse LeNeo is fully automatic and can process a wide range of samples such as:

  • Cement, lime, carbonates, ceramics, glass, slag, refractories
  • Mining and geological samples, silica, silicates, clay, ores
  • Sulfides, fluorides
  • Bauxites, alumina
  • Catalysts, polymers, pigments
  • Steel, pure metals, ferroalloys, non-ferrous alloys
  • Pharmaceutical samples


Electrical:Voltage: 208-240 V
Current: 20 A
Frequency: 50/60 Hz
230 VAC
20 A
50 Hz
Dimensions:52 x 55 x 55 cm (20.5 x 22 x 22 in.)
Weight:36 kg (80 lb.)
