Epsilon 1 Wells

For faster well interventions

The Epsilon 1 Wells is an on-asset monitoring solution that gives you critical production chemistry and flow assurance data within minutes. It maximizes uptime and production by giving you the ability to make data driven decisions about production parameters.

The application landscape focuses on scale management, well treatment surveillance, production constituents tracking and solids characterization - in almost real-time. The DNV Marine certification ensures continued operation in the harsh offshore environment.

見積依頼 デモ依頼 お問い合わせ

Features and Benefits

Small equipment

Our solution requires very limited space, making it possible to place it on the site. Having the analysis equipment on-site eliminates downtime and the cost needed to send samples onshore for analysis.

Small equipment

Robust solution

Platforms often shake from the wind and waves and corrosion is always a worry. Robustness is needed to endure this environment - the robustness of the Epsilon 1 Wells is proven by Shell, with multiple systems in use on their platforms.

Robust solution

Quick analysis

It takes only ~20mins to fill a 10mL sample cup, and 20 mins to run the device. Production constituents’ data are available in under 1 hour.

Quick analysis

Simple operation

The Epsilon 1 Wells is easy to operate for rig personnel - no special lab technicians are needed, saving you money.

Simple operation

Key Applications

  • Water composition: produced water, injection water, flowback water, aqueous treatment chemicals, scale formation, proppants, corrosion inhibitors
  • Scale composition elements: barium, calcium, strontium, sulfur, phosphorus and more
  • Oil composition: sulfur, nickel, vanadium, and other contaminants
  • Sand/solid/metal composition, emulsion/sludge estimation
  • Production contaminants monitoring (e.g. mercury and others), condensate impurities


Epsilon 1 Wells solution accessories and smart-install:

  • Guided Self-install or Self-installation training and package
  • Heavy-duty flight case suited for transport by helicopter and ship
  • Starting kit for successful sample preparation
  • Pre-assembled sample cups
  • Protective foils for optics
  • Set of syringes and filters


Sample handling X-ray tube Detector Software features
Highly repeatable sample positioning High-stability ceramic side window High-resolution, typical 135 eV Operator mode with big buttons for easy operation
Typical 5 ml liquid 50 micrometer thin window (Be) 8 micrometer thin window (Be) Advanced mode with many features
Spillage protection against liquids Silver anode, ideal for sulfur analysis High count-rate capacity --
Robustness improvements to be compliant to DNV Marine Class Guidelines Software-controlled, max voltage 50 kV -- --

Guided Smart Install

When correctly installed your new Epsilon 1 will give you reliable analysis results. Installing an Epsilon 1 is straightforward: unpack the system, plug it in and follow the instructions, which we will guide you through. Finally, a simple radiation test completes the installation and confirms that your system is working safely. Yes, it is that easy to start using your Epsilon 1. And, more importantly, you can rest assured that your system is supplied with the necessary safety certification.

Smart install ensures you can get new instruments up and running even when unexpected circumstances or remote locations prevent an engineer from accessing your facility. For the Epsilon 1, we offer a guided  smart installation, enabling you to install the system yourself and maintain the integrity of the instrument and its safety certification.

The advantages of guided smart install:

  • Get up and running fast
  • Save on installation costs
  • Install the system when it suits you
  • Extended 15-month warranty period

Find out more about smart install.



Solutions to maximize the return on your investment

To assure that your instrument remains in top condition and performs on the highest level, Malvern Panalytical offers a wide range of services. Our expertise and support services assure an optimal functioning of your instrument.


Service for a lifetime

  • Phone and remote support
  • Preventive maintenance and checkups
  • Flexible Customer Care Agreements
  • Performance certificates
  • Hardware and software upgrades
  • Local and global support


Adding value to your processes

  • Sample preparation development/optimization
  • Analytical methodologies
  • Turnkey solutions for XRD
  • Operations via IQ/OQ/PQ, quality assurance (GLP, ISO17025) or round robins/inter laboratory studies
  • Automation of lab processes
  • Consultancy services

Training and education

  • Training on-site or at our competence centers
  • Broad range of basic and advanced courses on products, applications and software

Analytical services and calibration materials

  • Expert (XRF) analyses services
  • Oxides and trace analysis
  • Customized calibration materials
